uninterruptible power supply (UPS)

Contributor(s): Robert McFarlane, Toon Diegenant and Patrick Tierce

An uninterruptible power supply (UPS) is a device that allows a computer to keep running for at least a short time when the primary power source is lost. UPS devices also provide protection from power surges.

A UPS contains a battery that "kicks in" when the device senses a loss of power from the primary source. If an end user is working on the computer when the UPS notifies of the power loss, they have time to save any data they are working on and exit before the secondary power source (the battery) runs out. When all power runs out, any data in your computer's random access memory (RAM) is erased. When power surges occur, a UPS intercepts the surge so that it does not damage the computer.

UPS in the data center

Every UPS converts incoming AC to DC through a rectifier and converts it back with an inverter. Batteries or flywheels store energy to use in a utility failure. A bypass circuit routes power around the rectifier and inverter, running the IT load on incoming utility or generator power.

While UPS systems are commonly called double-conversion, line-interactive and standby designs, these terms have been used inconsistently and manufacturers implement them differently: At least one system allows any of the three modes. The International ElectroTechnical Commission (IEC) adopted more technically descriptive terminology in IEC Std. 62040.

Types of UPSs and their core features

Voltage and frequency independent (VFI): Voltage and frequency independent (VFI) UPS systems are called dual or double conversion because incoming AC is rectified to DC to keep batteries charged and drive the inverter. The inverter re-creates steady AC power to run the IT equipment.

energy saving 1
Figure 1.

When power fails, the batteries drive the inverter, which continues to run the IT load. When power is restored, either from the utility or a generator, the rectifier delivers direct current (DC) to the inverter and simultaneously recharges the batteries. The inverter runs full time. Utility input is completely isolated from the output, and bypass is only used for maintenance safety or if there is an internal electronics failure. Since there is no break in the power delivered to the IT equipment, vacuum fault interrupter (VFI) is generally considered the most robust form of UPS. Most systems synchronize the output frequency with the input, but that's not necessary, so it still qualifies as frequency independent.

energy saving 2
Figure 2.

Every power conversion incurs a loss, so the wasted energy has historically been considered the price of ultimate reliability.

Voltage independent (VI): Voltage independent (VI), or true line interactive UPSs have a controlled output voltage, but the same output frequency as the input. Frequency independence is rarely a concern with power in developed countries. Utility power feeds directly to the output and IT equipment, and the rectifier keeps the batteries charged. The inverter is paralleled with the output, compensating for voltage dips and acting as an active filter for voltage spikes and harmonics. Rectifier and inverter losses only occur when incoming power fluctuates. Flywheels and motor/generator sets also qualify as VI.

energy saving 3
Figure 3.

When incoming power fails, or the voltage goes out of range, the bypass quickly disconnects from the input and the battery drives the inverter. When input power is restored, the bypass re-engages the input, re-charges the batteries and keeps output voltage constant. UPS vendors who use paralleled power sources claim no loss of reliability. The result is around 98% energy efficiency.

energy saving 4
Figure 4.

Voltage and frequency dependent (VFD): Voltage and frequency dependent (VFD), or standby UPS, is operationally similar to VI and is sometimes mistakenly called line interactive. In conventional VFD systems, the inverter is turned off, so it can take as long as 10 to 12 milliseconds (ms) to start creating power. That break can crash servers, making legacy VFD UPSs a bad fit for data centers.

energy saving 5
Figure 5.

New VFD concepts have the inverter producing power within 2 ms after being activated. The bypass is normally engaged, just as with VI, so equipment operates directly from the utility or generator. Since the inverter isn't working until power fails, there is no voltage control or power consumed, enabling efficiencies as high as 99%. Power failure or voltage outside of range opens the bypass switch, disengaging input from the output; the inverter starts operating from the batteries. The rectifier is only large enough to keep the batteries charged.

energy saving 6
Figure 6.

Advantages and disadvantages of UPS

Advantages to using uninterruptable power supplies include:

  • No delay between switching from the primary power source to the UPS.
  • Can better support critical instruments compared to generators.
  • Consumers can choose the type and size of UPS, depending on the amount of power they need to supply to a device.
  • UPSs are silent.
  • Maintenance of UPS systems is cheaper compared to generators.

Disadvantages to using uninterruptable power supplies include:

  • The inability to run heavy appliances- because UPSs are run off of batteries.
  • If substandard batteries are used, users may end up replacing the batteries often.
  • UPSs may need professional installations.

UPS VS. generators, surge protectors, inverters and AVRs

Unlike UPSs, generators do not seamlessly keep devices running once the primary device is lost. However, generators do provide power for a longer period of time compared to UPSs. UPS systems don’t provide power as long because batteries power them.

Surge protectors (suppressors) help prevent surges and high voltage spikes. However, surge protectors do not operate during power outages, or instances were the main power supply is cut from use.

Power inverters are devices that convert DC to AC. Power inverters are typically connected to an exterior DC source and continuously convert the current to AC. Power inverters commonly use one or more batteries to store power. Using power inverters, there is a delay in the transfer of power from a primary power source to a secondary power source when the main power is cut.

Automatic voltage regulators (AVRs) will control input voltages to minimize voltage fluctuations. AVRs are commonly used in both power converters and inverters.

This was last updated in May 2019
